determine a location for the ram-air super-scoop™.
it should be placed directly behind the grille as low as
possible, but not lower than the bottom edge of the radiator
with the air inlet opening pointing straight ahead.
(figures
8, 9 )
if the grille is angled, trim the scoop with heavy snips
or a hacksaw so the air inlet opening fits against the
backside of the grille and the scoop is level to the ground.
The height difference between the scoop and the
filter airbox inlet should be as much as possible, to
prevent excess rainwater from entering the airbox. Trim back
the curved outlet section of the scoop if less curvature makes
a more streamlined hose routing.
Mount the super-scoop using one of the following
methods: if the grille consists of horizontal bars or a
rigid perforated screen, the super-scoop can be secured with
four 14-inch cable ties, provided, slipped through its “ears”
and the grille. alternately, mount the super scoop with the
four perforated metal straps, provided. bend and attach them
to the super-scoop “ears” with the
1 ⁄
4
-20 x 1 1 ⁄
4
” bolts, nylock
nuts and 1 ⁄
4
-inch flat washers provided. attach the other ends
of the brackets to a convenient mounting surface, such as the
gravel pan or grille brackets, with 10 x
3 ⁄
4
sheet metal screws
provided. a combination of cable ties and straps can also be
used. The super-scoop may also be mounted to the grille by
screws placed through holes drilled in the lip flange of the
scoop. (figure
10 )
p.n. 96373 v.3.0 9
FIGURE 9
42.
43.
44.
45.
