the rubber grommets. Remove the
muffler and tailpipe assembly from the
vehicle. If applicable, remove the
muffler gasket and the factory clamp,
these will no longer be used.
5.
Install the Banks 3" V-band clamp
onto the flare of the Banks
intermediate pipe. Install the Banks
intermediate pipe to the factory Y-pipe
outlet. Align the V-band Clamp over the
flare and y-pipe adapter. Lightly tighten
the 3" V-band clamp (see
Figure 2).
6.
Install the 3" exhaust clamp onto
the inlet of the Banks Monster Muffler
(Note the inlet labeling of the muffler).
Orient the “Monster” logo such that it is
parallel with the frame rail. Install the
Banks Muffler inlet onto the intermediate
pipe and lightly tighten the 3" hanger
clamp (see Figure 2).
NOTE: All clamps should be positioned at
the beginning of the slots (on the
1 ⁄ 2
circle punch) and evenly tightened.
7.
Install the 3" dual hanger clamp
onto the Banks Muffler outlet such that
the hanger pins are facing forward.
Install the two (2) clamp hanger pins
into the corresponding vehicle rubber
grommets (see
Figure 2).
8.
From the vehicle rear, route the
tailpipe over the rear end. Start the
tailpipe hanger pin into the
corresponding vehicle rubber hanger.
Install the tailpipe into the Banks
Muffler outlet. Lightly tighten the rear
muffler hanger clamp to secure the
tailpipe (see
Figure 3).
Figure 3
97059 v.4.0
5
