32
96800 v.1.0
from the intake manifold to the
pressure chamber. The straight hose
end connects to the intake manifold
and the 90º hose end connects to the
pressure chamber. See
Figure 38.
Carefully measure the necessary
length of hose and cut to size. See
“Hose and End Fitting Assembly” on
page 39 for instructions on how to
assemble the hose.
9.
Install the hose and tighten the
fittings.
-END, SECTION 8-
Figure 38
