SIX-GUN POWER LEVEL SELECTION SWITCH INSTALLATION
Caution: Do not use force when
working on plastic parts.
Permanent damage to the part
may result.
12.
The Six-Gun switch will be
installed on the driver’s side of the
instrument panel (IP) next to the
steering column (see
Figure 4).
Carefully remove IP from the
dashboard by slowly pulling IP,
allowing the pins to pull free from the
dashboard sockets. Automatic vehicles
will need to set the parking brake and
move the shift lever down to the
lowest gear.
13.
Cut out the supplied template
(see
Figure 9 on page 23) and align
the template onto the rear of the IP
over the IP alignment pin and
mounting pin (see
Figure 5).
14.
Using a
3
⁄
8
" Uni-drill bit, center
the bit onto the
3
⁄
8
" drill location on
the template and slowly drill through
the IP. Using a
1
⁄
8
" drill bit, center and
drill through the
1
⁄
8
" location on the
template. Remove and discard the
template and any plastic shavings.
15.
On the frontside of the IP, align
the Banks Six-Gun label onto the
previously drilled hole (see
Figure 6).
16.
Remove the nut and internal
tooth washer from the Six-Gun Switch.
Rotate the shaft counter clockwise
until the shaft stops. Verify the locating
washer tab is inserted into the #6
position on the switch (see
Figure 7).
NOTE: If the washer is in any position
other then the #6, your Six-Gun Diesel
Tuner will not select power levels
properly.
17.
After confirming the locating
washer is in the #6 location, install the
switch through the
3
⁄
8
" hole on the
backside of the instrument panel. The
alignment pin should rest in the
1
⁄
8
"
hole and with the switch fully rotated
counter clockwise; the shaft’s flat side
should be facing the steering column.
Secure switch with internal tooth
washer and nut. Snug the washer; be
careful not to over torque the nut and
damage the plastic threads.
18.
Install the knob onto the shaft
facing the #1 Level on the Six-Gun
label. On the knob, snug the two (2)
set screws with the supplied 0.050
"
hex key wrench.
19.
Route the Six-Gun Switch wires
down to the Six-Gun Diesel Tuner and
reinstall the IP to the dashboard.
20
.
Remove the 2-pin Jumper from
the Six-Gun Diesel Tuner wire harness.
Connect the Six-Gun harness to the
2-pin connector on the switch wire.
-END, SECTION 3
