96496 v.6.0
9
9.
Push the air cleaner bellows away
from the air filter housing while pulling
up on the MAF side of the air filter. Lift
and remove the air filter housing in the
direction shown in Figure 7.
10.
Locate the supplied Banks MAF
sensor gasket. Install the supplied
gasket under the MAF sensor.
11.
Install the MAF sensor to the
Banks Intake Tube using the supplied
screws. Make sure the MAF sensor
connection is on the same side as
where the restriction gauge will go.
Note: Do not over tighten the screws.
12.
Attach the Banks Air Filter
Element to the Banks Intake Tube with
the supplied hose clamp. An audible
snap should be heard when installing
the Filter to the Tube. Tighten to 44
lb-in (5 Nm).
CAUTION: Filter may come loose
at connection point due to oil
residue. Clean the air filter
connection points with a non-oil
based solvent such as Acetone,
Mineral Spirits, Denatured
Alcohol, or Lacquer Thinner. Read
and follow the manufacture’s
operation instruction for non-oil
based solvent cleaner. Be careful
not to apply cleaner to cotton
filter media or damage to media
may result.
13.
Install the restriction gauge’s
rubber grommet to the Banks Intake
tube.
14.
Install the Banks Ram-Air Filter
Housing. Line up the fresh air intake
with the matching opening on the
Banks Ram-Air Filter Housing (Figures
8, 9). The three feet on the bottom
of the Filter Housing will go into the
Figure 7
