www.vanco1.com 800-626-6445
4
HDMI® 3 x 1 Switcher with IR Control
Part # 280711
• 3 HDMI Inputs to 1 HDMI Output
• High Speed Chip Set that Supports 3D, 4K x 2K
• Full HD1080P/60HZ
• HDCP Compliant
• Super IR control system, IR transport channel
can be forward or backward, an IR adapter and
transmitter and receiver pigtails are needed
• Supports Digital Audio Format, DTS-HD/Dolby-
True HD/LPCM7.1/AC3/DTS/DSD
• Unique Circuit Design Allows for Protection
against High Voltage and Peak Currents
• Tested for Compatibility with all leading HD
Video brands
• Tested with Dolby 7.1 Home Theater Systems
• Smart switching technology
• Shelf Mounting
• 5V DC, UL Listed Power Supply for Transmitter
• Dimensions: 4.375”W x .875”H x 2.875”D
SPECIFICATIONS
HDMI version ............................................................ HDMI v1.4 with 3D
HDCP version ............................................................ HDCP1.2
Support HDMI resolution ............................................ 1080P/1080i/720P/576i/480P/480i
Support video color bi ................................................. deep color 24bit/36bit
Support Audio Format ................................................ LPCM/Dolby-AC3/DTS7.1/DSD
Input Video signal ...................................................... 5.0Volts/P-P
Output cable distance ................................................. 66 ft 24AWG Cable
Input cable distance ................................................... 66 ft 24AWG Cable
Data transfer speed ................................................... 6.75Gbps
Operating Humidity range ........................................... 5 to 90%RH (No Condensation)
Operating Temperature range...................................... 15 to +55 Degrees C; 5 to 131 Degrees F
Power adapter format ................................................ Input AC (50Hz.60Hz) 100-240V
Power Supply ............................................................ DC 5V
