FEATURES
Super IR Control
These units have the capability of being controlled via IR signals. The switch can be controlled from the
display. This is accomplished by using an optional IR Receiver pigtail (Part # 280721) pointing away from the
display(s), which can be connected with the optional HDMI IR Adapter (Part # 280703), and inserted between
the HDMI cable connector and the display with the toggle switch at the “IR” position. The IR Transmitter pigtail
(Part # 280720) is then connected to the switch and pointed at the source(s). A remote control is used at the
display to select switch inputs and outputs.
*** These products are only compatible with Vanco’s Super HDMI IR Accessories.
Over-Current Over-Voltage Protection
The circuit boards are equipped with both over-current and over-voltage protection and automatically power
down if these are encountered. The power circuit will restore itself automatically once the excessive current or
voltage conditions are rectified.
HDMI® 5 x 1 Switcher with IR Control
Part # 280710
• 5 HDMI Inputs to 1 HDMI Output
• High Speed Chip Set that Supports 3D, 4K x 2K
• Full HD1080P/60HZ
• HDCP Compliant
• Super IR control system, IR transport channel
can be forward or backward, an IR adapter and
a transmitter and receiver pigtails are needed
• Supports Digital Audio Format, DTS-HD/Dolby-
True HD/LPCM7.1/AC3/DTS/DSD
• Unique Circuit Design Allows for Protection
against High Voltage and Peak Currents
• Tested for Compatibility with all leading HD
Video brands
• Tested with Dolby 7.1 Home Theater Systems
• Smart switching technology
• Shelf Mounting
• 5V DC, UL Listed Power Supply for Transmitter
• Dimensions: 4.375”W x .875”H x 2.875”D
