Connection diagrams, Super ir control system over utp cable, Blu-ray player hdtv sender receiver – VANCO 280715 (100ft wall plate) User Manual
Page 7
www.vanco1.com
800-626-6445
7
CONNECTION DIAGRAMS
Super IR Control System Over UTP Cable
Blu-Ray
Player
HDTV
Sender
Receiver
IR TX
Pigtail
IR
IR
RX Pigtail
IR Remote
HDMI
HDMI
2 UTP
Cables
(1 per display for Matrix, Switches, Extenders
1 per source for Splitters)
Video Output
DVD/Satellite box–Signal Source
HDMI Output
DVD/Satellite box–Signal Source
