www.vanco1.com 800-626-6445
4
HDMI® Extender over 2 UTP Cables with IR Control
(30m/100 ft)
Part # 280713
• Allows HDMI Audio/Video Signals to be
transmitted over Dual Cat5e/Cat6 Cables
• Transmission Range: Extends 1080p
resolutions up to 100 ft over Cat5e Cables;
Extends 1080p resolutions up to 110 ft over
Cat6 Cables
• High Speed Chip Set that Supports 3D, 4K x 2K
• Full HD1080P
• HDCP Compliant
• Super IR control system, IR transport channel
can be forward or backward. IR transmitters
and receivers are needed (Part #s 280720,
280721)
• Supports Digital Audio Format, DTS-HD/Dolby-
True HD/LPCM7.1/AC3/DTS/DSD
• Unique Circuit Design Allows for Protection
against High Voltage and Peak Currents
• Tested for Compatibility with all leading HD
Video brands
• Tested with 7.1 Home Theater Systems
• Shelf or Wall Mountable
• No power supply – Requires Source that
Provides 5V DC HDMI Signal
• Dimensions: 1.25”W x .875”H x 3.25”D
HDMI® Wall Plate Extender over 2 UTP Cables with IR
Control (50m/164 ft)
Part # 280725
• Allows HDMI Audio/Video Signals to be
transmitted over Dual Cat5e/Cat6 Cables
• Transmission Range: Extends 1080p
resolutions up to 164 ft over Cat5e Cables;
Extends 1080p resolutions up to 180 ft over
Cat6 Cables
• High Speed Chip Set that Supports 3D, 4K x 2K
• Full HD1080P
• HDCP Compliant
• Super IR control system, IR transport channel
can be forward or backward. IR transmitters
and receivers are needed (Part #s 280720,
280721)
• Supports Digital Audio Format, DTS-HD/Dolby-
True HD/LPCM7.1/AC3/DTS/DSD
• Unique Circuit Design Allows for Protection
against High Voltage and Peak Currents
• Tested for Compatibility with all leading HD
Video brands
• Tested with 7.1 Home Theater Systems
• 5V DC, UL Listed Power Supply for Receiver
• Dimensions: 2.75”W x 4.5”H x 1.25”D
• Fits single-gang box
