Toner Cable LCD-501X3 Three 5" HD LCD Monitors in Rack Mount User Manual
Color hd lcd monitor

Specifications Subject To Change Without Notice
Rev 06-12
©Toner Cable Equipment, Inc.
LCD-501 & LCD-501X3
Color HD LCD Monitor
969 Horsham Road
l
Horsham, Pennsylvania 19044 USA
l
Phone: 215-675-2053 Fax: 215-675-7543
l
Model Numbers.................................................................................
LCD-501
LCD-501X3
Three Monitors in Rack Mount
Description........................................................................................
Wide operating power range (10 ~ 30VDC)
Picture on demand/power saving feature
Front mounted stereo headphone jack for private
listening (no built-in speakers)
Slim space saving design
Compact and light weight for easy installation or mobile use
Low power consumption
Case made of durable ABS plastic
Active matrix technology allows wide viewing angle
Front controls for color, brightness and audio volume
A/C adaptor, Part No. AC-2000, included
Optional Accessories.......................................................................
BP-563
Rechargeable 2200mAH battery pack pro-
vides approximately 5 hrs. of operation
DC-12
Car Cord
DC-12D
Dual car cord
HS-1
Hot Shoe mount
LM-BR-501
Brass Flush Mount Kit
Requires rear access to install
Dimensions (WH): 5.82" x 5.43"
Installer’s cut-out: 5.15"(W) x 4.44"(H)
MB-72M
Metal Mounting Bracket
MB-1
Desk Stand
WM-1
Wall mount bracket
Specifications....................................................................................
Resolution
600(H) x 234(V) dots
Brightness Rating
240 cd/m² (Nit)
Dot Pitch
0.171(H) x 0.316(V)
Contrast Ratio
120:1
Display
5" TFT LCD active matrix
Active Area
102.6(H) x 73.9(V)
Back Light
CCFT
Input Signal
NTSC/PAL (auto switching)
Number of Pixels
140,400
Pixel Configuration
Stripe
Operating Power
10 ~ 30 VDC
Range
Input Signal Level
1.0V P-P (positive) 75 Ohm
Audio Input Level
1.0V P-P
Audio Output
0.3 W
Audio Input
10K ohm
Impendance
Audio Band Width
15 KHz
Viewing Angle
55°/55°/15°/35°
(L/R/T/B)
Dimensions (WHD)
146 x 105 x 30.5mm/5.7" x 4.1" x 1.2"
Monitor Mounting
Mounting pad with ¼ - 20 threaded socket
Actual Visible screen 102 x 74mm / 4" x 2.9"
Size (WH)
Operating Temp
50 ~ 104°F or 10 ~ 40°C, 85% RH max.
Storage Temp
-4 ~ 140°F or -20 ~ 60°C, 85% RH max.
Power Requirement / 12VDC (1A, + pin) / 7 W (max.)
Consumption
DIN Cable
RCA video IN
Connections
RCA right audio IN
RCA left audio IN
2.1 DC IN jack
LCD-501 Weight
Net 363g / 12.8oz Gross 1.2 kg / 2.7 lbs
LCD-501X3 Weight
Net 2.4kg / 5.3lbs Gross 5.3kg / 11.8 lbs
