LX102
V. 01 – 06/06/2012 6 ©Velleman nv
Use the and buttons to navigate the menu map and menu options. Press to
access the menu function currently displayed or to enable a menu option. To return to the previous
option or menu without changing the value, press the
7.2 Menu Functions
menu sub-menu function description
… built-in programs select between switching and fading built-in programs
speed set speed of built-in programs ( ~ )
address set DMX address ( ~ )
channel mode
select 2-channel DMX mode
select 3-channel DMX mode
select 7-channel DMX mode
dimming speed
no dimming speed
fast dimming speed
middle dimming speed
slow dimming speed
… colour mixing select between 9 static colours
warm white dimmer ( ~ )
cold white dimmer ( ~ )
strobe speed add strobe effect ( ~ )
7.3 Stand-Alone Mode
Auto Mode
1. Press
is displayed.
2. Press to confirm your selection.
3. Use or to select the desired program (
~ ).
4. Press to confirm your selection.
5. Set the speed of built-in programs via or (
~ )
6. Press to confirm your selection.
Preset Colours
This device has pre-programmed static colours.
1. Press
is displayed.
2. Press to confirm your selection.
3. Use or to select the desired program (
~ ).
4. Press to confirm your selection.
Custom Static Colours
This device allows you to create custom static colours.
1. Press
is displayed.
2. Press to confirm your selection.
3. Use or to scroll through the options:
o
… = warm white intensity ( ~ , from 0 to 100%)
o
… = cold white ( …) intensity ( ~ , from 0 to 100%)
o
… = strobe speed ( (off) ~ (max.))
4. Press to select the desired sub-menu and use or to change the value.
5. Press to confirm the setting.
6. Press again to exit the menu.
