AVMOD11TX – AVMOD11TXB – AVMOD11TXC – AVMOD12TXM – AVMOD11RX – AVMOD13RX – AVMOD13TXMA VELLEMAN
1
AVMOD SERIES 11 / 12 / 13 – VIDEO TRANSMITTER MODULE
1. Introduction
To all residents of the European Union
Important environmental information about this product
This symbol on the device or the package indicates that disposal of the device after its lifecycle could harm the environment.
Do not dispose of the unit (or batteries) as unsorted municipal waste; it should be taken to a specialised company for recycling.
This device should be returned to your distributor or to a local recycling service.
Respect the local environmental rules.
If in doubt, contact your local waste disposal authorities.
Thank you for buying a Velleman product. Read this manual carefully before using the device.
Only for use in following countries: Austria, Belgium, Denmark, Finland, France, Germany, Italy, Luxemburg, the Netherlands, Norway and United Kingdom.
SPECIFICATIONS
AVMOD11TX
AVMOD11TXB
AVMOD11TXC
AVMOD12TXM
AVMOD11RX / 13RX
AVMOD13TXMA
Frequency (4 channels)
2.412 – 2.452 – 2.472 –
2.432GHz
2.412 – 2.452 – 2.472 –
2.432GHz
CMOS 1/3”, 330000 pixels, 380
TV lines, lens 5.6mm / 72°
- - -
2.412 – 2.452 – 2.472 –
2.432GHz
2.412 – 2.452 – 2.472 –
2.432GHz
Frequency (1 channel)
2.472GHz
2.472GHz
RF Output Power
EC R&TTE compliant
EC R&TTE compliant
EC R&TTE compliant
EC R&TTE compliant
EC R&TTE compliant
EC R&TTE compliant
Operating Power
DC12V, regulated
DC12V, regulated
DC4.8-7.2V, regulated
DC4.8-7.2V, regulated
DC12V
DC5-7V
Power Consumption
70mA
70mA
80mA with 4 AA-batteries
50mA
220mA
55mA
Dimensions
15 x 50 x 12mm
15 x 95 x 30mm
18 x 34 x 22mm
15 x 22 x 7mm
155 x 88 x 40mm
17.8 x 17.8 x 5mm
Antenna
omnidirectional
built-in & omnidirectional
omnidirectional
omnidirectional
directional antenna
omnidirectional
Transmitting Range
max. 100m (line of sight)
30m indoors
max. 100m (line of sight)
30m indoors
max. 100m (line of sight)
30m indoors
max. 100m (line of sight)
30m indoors
max. 100m (line of sight)
30m indoors
Temperature
-10 to +55°C
-10 to +50°C
-10 to +50°C
-10 to +55°C
-10 to +55°C
Video Input/Output
IN 0.4V – 0.6V/75
Ω
IN 0.4V – 0.6V/75
Ω
none
IN 0.4V – 0.6V/75
Ω
OUT : 1Vp-p/75 ohm
IN 0.4V – 0.6V/75
Ω
Audio Input/Output
IN 0.4V – 0.6V/600
Ω
IN 0.4V – 0.6V/600
Ω
none
none
OUT : 0.8V/600 ohm
none
Audio Bandwidth
none
none
50 – 17000Hz
Microphone
external and OPTIONAL
built-in, very sensitive
- - -
- - -
- - -
built-in
Weight
25gr
32gr
15gr
5gr
150gr
10gr
Modulation
FM
FM
FM
FM
FM
FM
Wires
yellow (video in), red (audio
in), black (power adapter)
black (power adapter)
black (power adapter)
black (power adapter), yellow
(video in)
yellow (video out), red (audio
out), black (power adapter)
white (video in), black (- power
supply), red (+ power supply)
Receiver
AVMOD11RX
AVMOD11RX
AVMOD11RX
AVMOD11RX & 13RX
- - -
AVMOD13RX
The best results are achieved when there is a clear line of sight between transmitter and receiver. Try to avoid obstacles e.g. trees, walls, vehicles, etc. Transmitting in the rain and over bodies of water
will reduce the quality of the performance. Proximity to certain electronic equipment may also influence the effective range.
Optimum reception is obtained when transmitter and receiver are placed 4.5 to 6ft (= 1.5 to 2m) above the ground. Test all devices prior to their installation because the transmission quality can often be
improved by moving the components slightly.
Turn the transmitter and the receiver off when they are not in use. Do not touch the antennas when the system is in use and do not place the receiver behind a monitor.
