8. Technical specifications
IP rating IP68
scanning system PAL
pick-up element Sony EXVIEW HAD ultra-high sensitivity double speed CCD sensor
image size 1/3"
number of pixels 752(H) x 582(V) pixels
resolution 580 TV lines
min. illumination 0.05 lux (IR off)
LED wavelength 840nm (40°)
max. IR projection distance ± 50m (42 units)
IR power on < 10 lux by CDS auto control
interlace 2:1
video output level
1.0Vpp, 75 ohms, composite
video S/N ratio > 52dB (AGC off)
white balance 2400K ~ 11000K
electronic iris ON
AEI 1/50 ~ 1/100 000s
gamma 0.45
varifocal lens
type 3.6~9mm
iris
F1.6 (3.6mm) ~ F2.4 (9.0mm)
lens angle H: 31.66°~77.18° / V: 23.73°~56.73°
operating temperature -10°C ~ 50°C
humidity < 90° RH
power supply DC power supply through coaxial cable (power supply unit incl.)
power consumption (max.) 6.5W
fuse 250V/2A (FF2N)
dimensions
camera 116 x 87mm (Ø)
bracket 140 x 70mm
cable length 30m
power supply unit 44 x 218 x 96mm
weight
camera 1080g
power supply unit 770g
Use this device with original accessories only. Velleman nv cannot be held responsible
in the event of damage or injury resulted from (incorrect) use of this device. For more
info concerning this product, please visit our website www.velleman.eu. The
information in this manual is subject to change without prior notice.
