5. Overview
Refer to the illustrations on page 2 of this manual.
camera 4
sunshield
1 lens 5 camera bolt
2 IR LEDs 6 position bolt
3 light sensor 7 bracket
power supply D fuse
A on/off switch E brightness switches
B power LED (green) F camera connector
C mains connector G monitor connector
Hardware setup 3 to monitor
1 monitor connection 4 AC power cord
2 to camera 5 coaxial power supply
6. Installation
Refer to the illustrations on page 2 of this manual.
• Choose a location for the camera, keeping following guidelines in mind
• Do not install the camera in locations where extremely high or low temperatures or
excessive vibrations may occur.
• Avoid mounting the camera near high electro-magnetic fields.
• Do not aim the camera at the sun or other extremely bright objects.
• Do not install behind a glass (or other) window as this will impact image quality.
• Mount the mounting bracket [7] on a wall or ceiling with the 3 included screws.
• Screw the camera on the bracket with the camera connection screw [5]. Note that the camera
has two mounting holes on either side, for wall or ceiling mounting.
• Point the camera towards the field of interest and secure it by turning the butterfly nut [6].
• The other side of the RG58U cable must be connected to connector [F] of the coaxial power
supply.
• Connect a monitor (not incl.) to connector [G] (cable not incl.).
• Plug the mains connector [C] in the mains (230V/50Hz).
• Switch on the coaxial power supply with switch [A]. The status LED [B] turns green.
• Adjust the brightness of the camera image by setting the dip-switches [E] on the back of the
power supply. The two upper-switches increase the brightness (brighter), while the two lower
switches decrease the brightness (darker).
• In case of a blown fuse [D] in the power supply, replace it with a 250V/2A fuse.
7. Adjusting zoom and focus
Refer to the illustrations on page 3 of this manual.
• Locate the hex head screw at the bottom of the camera (see arrow).
• Release this screw with the included Allen wrench and slide the housing towards the front of
the camera. The focus [a] and zoom [b] magnet become visible.
• First adjust the zoom magnet [b]. Slide it upwards to zoom in (longer distance, smaller
viewing angle); slide it downwards to zoom out (shorter distance, wider viewing angle)
• Then adjust the focus magnet [a]. Slide it upwards or downwards to adjust focus hence
making the images sharper.
• Slide the housing back in place and secure it with the hex head screw. Do not apply excessive
force on the screw.
