Ab (sata) – Velleman IVSPROM2 Quick Installation Guide User Manual
Page 3
IVSPROM2
V. 02 – 02/05/2012
3
©Velleman nv
A
B (SATA)
power supply
data bus
voeding databus
alimentation
bus de données
alimentación
bus de datos
Stromversorgung Datenbus
1 DC 12V input terminal
2 Video output connector
1 DC 12V ingangsaansluiting
2 Video-uitgangsaansluiting
1 Connexion d’entrée CC 12V
2 Connexion de sortie vidéo
1 DC 12V-Eingangsanschluss
2 Video-Ausgangsanschluss
1 Conexión de entrada CC 12V
2 Conexión de salida de vídeo
* not incl. - niet meegelev. - non incl. - no incl. - *nicht mitgeliefert
