4. Features
• converts audio/video line level signals from a DVD player, video game
system, camcorder or other device to an RF signal and adds this signal as
extra channel on the antenna cable to enable multiple TV connections
• easily distribute video-signals over an RF network
•
connects one audio/video device to a television set
•
selection between different video channels
5. Overview
Refer to the illustration on page 2 of this manual
1 antenna/cable input 6b audio in - R
2 TV/VCR/cable output 6c audio in – L
3 power input 7 power on/off switch
4 SCART input 8 channel down button
5 SCART output 9 channel up button
6a video input 10 channel display
6. Installation
•
Choose the appropriate location to insert the RF modulator into the
antenna/cable circuit. Keep in mind that only the devices physically
located behind the RF-modulator in the cable network will be able to
receive the extra inserted channel.
•
Connect an input device to the SCART input [4] or video [6a] & audio
inputs right [6b] and left [6c]. Do not switch it on yet.
• Connect the connector coming from the antenna or cable television input
to the antenna/cable input [1].
• Connect the TV/VCR/cable output [2] to a TV set or a cable network if
present inside the house.
•
Make sure the included power adaptor is compatible with your mains.
Plug the DC power adaptor into the power input [3]. Only use the
included adaptor or an adaptor with identical specifications.
• An extra device can be connected to the SCART output [5]. Note that this
is only a loop through connector thus receiving only the signal from the
connected input device. Other TV channels are not available at this
output.
•
Switch on the RF modulator by switching the power on/off switch [7] to
the ON position. The channel display [10] lights up and shows the
current channel on which the input signal will be broadcasted.
