AVMOD19
V. 02 – 17/09/2012 7 ©Velleman nv
4. Features
• wireless transmission of A/V signals through walls and between rooms
• uses 5.8 GHz frequency which gives less interference with other wireless
products than the 2.4 GHz frequency
• comes with: 2 x SCART to RCA A/V cable, IR extender cable and 2 power
adapters
• optional video cables: AVB020/2.0, AVB020/5.0, AVW084, AVW084G,
AVW085, AVW085G.
5. Overview
Refer to the illustrations on pages 2-3 of this manual.
1 – side view
A 5.8 GHz antenna (folded upwards)
B channel selector switch
C ON/OFF switch
D infrared remote output (transmitter only)
E remote frequency selector (transmitter only) A = 38 kHz; B = 56 kHz
2 – rear view
F power connector (12 VDC)
G S-video connector
H RCA video connector (yellow)
I RCA audio connector R (red)
J RCA audio connector L (white)
3 – accessories
K power adaptor (2 x)
L IR LED
6. Installation
Refer to the illustrations on pages 2-5 of this manual. Make sure all devices are
disconnected from the mains before making any connections.
Transmitter [5]
The transmitter can be recognized easily as it has an IR output port [D] and
remote frequency selector [E] at the side.
1. Use the SCART-to-RCA A/V cable marked with TRANSMITTER (included) or
use an appropriate S-video cable (not included).
Note: When using an S-video cable, the RCA connectors are disabled. Always use
an S-video cable on both transmitter and receiver.
2. Connect the RCA video connector (yellow) to the video connector [H] and
connect the audio connectors (red, white) to the audio connectors [I]
resp. [J]. When using an S-video cable, simply connect it to the S-video
connector [G].
3. Connect the SCART connector to a SCART output connector or connect the
free end of the S-video cable to the S-video output port of the signal
transmitting device (e.g. satellite receiver, DVD, VCR…, not incl.).
