DVR16H2
V. 01 – 28/03/2013 15 ©Velleman nv
Alarm sensor connection
Connect the alarm sensor, such as magnetic contacts, to the push video alarm-in terminal or I/O pins that
support push video on the DVR rear panel.
10.2 Configuration
Before configuring push video, make sure that:
The DVR system is set up as described in Connection and Setup.
The DVR is connected to internet.
You have installed the EagleEyes app on your iPhone, iPad, or Android mobile devices.
For details, please refer to Mobile Surveillance via EagleEyes.
To configure push video:
1. Right-click to show the main menu and select
(ADVANCED CONFIG) > NOTIFY.
2. Set GUARD to ON.
3. Configure your alarm sensor type (normal open or normal closed).
Careful! You have to select the opposite type for push video to work correctly.
If your alarm sensor is N.C. (normal closed, alarm goes off when the contact opens), then select
ALARM N.O.
If your alarm sensor is N.O. (normal open, alarm goes off when the contact closes), then select
ALARM N.C.
ADVANCED CONFIG
CAMERA
PUSH VIDEO PUSH MESSAGE MESSAGE MAIL VIDEO MAIL
DETECTION GUARD ON
ALERT CH01 ALARM OFF / INTERNAL ALARM  CH1
NETWORK CH02 ALARM OFF  CH2
DISPLAY CH03 ALARM N.O.  office
RECORD CH04 ALARM OFF  CH4
DEVICES
DCCS
IVS
NOTIFY
EXIT
