LEDS03RGB
V. 01 – 07/02/2012 4 ©Velleman nv
4. Use
Refer to the illustrations on page 2 of this manual.
a.
Installation
• Mount the LED strip in the desired location. The LED strip can be cut
every 10 cm (see [A]). The cut ends must be protected to avoid short-
circuits.
• Connect the LED strip to the controller [B2] (connecting tools not
included). Make sure to connect matching wire colours. Do not short-
circuit any wires.
• Connect the included power adaptor to the controller [B1]. Plug the
other end into the mains.
b. Use
• Aim the remote control [C] towards the IR LED [B3] of the controller to
control the output of the LED strip.
• Switch the LED strip on or off with the button on the remote control.
• Select the desired light output colour by pressing the corresponding
colour button on the remote control.
Note: If you want a different colour, you can define your own using the
DIY buttons. For more information, see further in this manual.
• To increase or decrease output brightness, press the or button
(8 gradations).
c. Using Effects
• Press the effect buttons to generate different effects: Auto, Flash,
Fade3 (3 colours), Fade7 (7 colours), Jump3 (3 colours), or Jump7
(7 colours).
• To increase the speed of the effects, press Quick. To decrease the
speed, press Slow.
• To pause the effect, press the button. Press the button again to
restart.
d. Creating Custom Colours
You can define and store up to 6 custom colours using the DIY1->6
buttons. When you press the DIY button, the LED strip will change to your
custom colour. For example, to store a colour for button DIY1:
• Press DIY1.
• Use the coloured
and buttons to mix your own colour.
• Press DIY1 again to store the colour. The LED strip will blink once when
the colour is stored correctly.
