CAMCOLVC18
V. 04 – 06/09/2013 7 ©Velleman nv
3. Slide the camera base in the handlebar bracket until it clicks into place
(see illustration D).
4. Adjust the camera position: loosen the ring [5], adjust, then tighten
again to keep the camera firmly in place.
5. To adjust the bracket position: loosen the bolt [14], reposition the
bracket on the handlebar, then tighten the bolt again (see
illustration E).
6. To take the camera off the bracket again, squeeze the camera base
handles [12] together and slide the camera off the bracket.
6.3 Mounting the camera on a helmet using the rubber strap
1. Thread the rubber strap [17] through the helmet bracket [15] (see
illustration F).
2. Fit the strap over the helmet with the bracket in the desired position
(see illustration G).
3. Make sure the strap fits tightly around the helmet.
4. Slide the camera into the bracket (see illustration H).
5. Adjust the camera position: loosen the ring [5], adjust, then tighten
again to keep the camera firmly in place.
6.4 Mounting the camera on a helmet using the hook-and-loop
strap
1. Thread the hook-and-loop strap [16] through the helmet bracket [15]
(see illustration F).
2. Place the bracket on the helmet in the desired position and thread the
strap through the helmet vents (see illustration I).
3. Tighten the strap and fix the ends together to keep the bracket in place.
4. Slide the camera into the bracket (see illustration J).
5. Adjust the camera position: loosen the ring [5], adjust, then tighten
again to keep the camera firmly in place.
7. Operation
7.1 Batteries
Do not puncture batteries or throw them in fire as they may
explode. Do not attempt to recharge non-rechargeable batteries
(alkaline). Dispose of batteries in accordance with local regulations.
Keep batteries away from children.
Replace the batteries when the low battery indication appears on the
display. When the batteries are completely empty, you will hear a long beep
and the camera shuts off automatically after 20 seconds.
Note: Always replace all batteries at once.
1. Make sure the camera is switched off.
