5. Fit the PIR onto the hooks of the bracket.
If necessary, open the sensor.
9. Understanding the LED
In normal operation mode, the LED indicator will not light except in
the following situations:
 When the PIR is in low battery condition, every time it transmits a
detected movement, the LED will flash for about 2 seconds.
 When the cover is opened and the tamper switch is violated, the
LED will light up for 2 sec. to indicate it is transmitting the tamper
signal to the control panel.
 When the tamper condition persists, the LED will light up every
time the sensor transmits a detected movement.
 If the pir is in test mode, the LED will light up every time a
movement is detected.
10. Test mode
 The sensor can be put into test mode by pressing the LED on the
front cover.
 In test mode, the power saving is disabled and the LED indicator
will flash every time a movement is detected.
 Every time you press the led on the front, the pir will transmit a
test signal to the control panel for radio range test and enter the
test mode for 3 minutes.
 The sensor quits test mode automatically after 3 minutes and
returns to normal mode.
11. Technical Specifications
power supply
1 x 3.6 V lithium AA type battery (incl.)
frequency 868.6375 MHz
range ± 200 m in open space (ideal circumstances)
operating
temperature
-20 to 50 °C
humidity up to 95 % non-condensing
dimensions 94 x 64 x 42 mm
weight 91 g
