5. Overview
Refer to the illustrations on page 2 of this manual.
1 test button / LED indicator
2 battery protection strip
3 tamper switch
4 corner mounting bracket
5 sensitivity switch
6. Battery
The detector comes with the battery already installed.
Low battery detection
The detector has a low battery detection system. Low battery
detection operates where the PIR has enough reserve energy to
typically operate for 1 month before complete exhaustion. A low
battery signal will be sent to the control panel along with regular
signal transmissions for the control panel to display the status
accordingly.
Replacing the battery
1. Put the control panel in configuration mode to avoid triggering
the tamper alarm (tamper alarm is not active in this mode).
2. Remove the screw at the bottom of the detector and separate
both parts.
3. Remove the battery.
4. Press the tamper switch twice to fully discharge before inserting
new batteries.
5. Insert a new battery (always use the correct battery type: see
Technical specifications). Make sure the polarity is correct.
6. Close the detector using the screw.
7. On the control panel, exit configuration mode.
WARNING
 Do not puncture or throw batteries in fire as they might
explode.
 Keep batteries away from children.
