9. Technical specifications
system PAL
monitor
size 7"
TFT
number of pixels
1440(H) x 234(V)
brightness 300cd/m²
viewing angle
90°
control unit
3 video inputs (2 with selectable mirror function)
1 video output
1 monitor output
camera
pick-up element
1/4" colour CCD image sensor
synchronization system
internal
horizontal resolution
420 TVL
effective pixels
500 (H) x 582(V) - PAL -
IR LEDs
18
min. illumination
0 Lux when IR on
lens F2.1
lens angle
145°
S/N ratio
>= 48dB (AGC OFF)
video input signal
1.0Vpp composite video signal at 75 ohm
video input connections
stereo mini jack 3.5mm TRS
power supply
DC 12V ~ 24V / 700mA ~ 400mA
cable
one single cable (power, video), length 20m
operating temperature
-10°C ~ +50°C
storage temperature
-25°C ~ +60°C
dimensions
monitor
170 x 128 x 22mm
bracket height
50mm
camera
75 x 90 x 50mm
control unit
130 x 75 x 30mm
weight
monitor ±405g
camera ±450g
control unit
±294g
total ±2.25Kg
Use this device with original accessories only. Velleman nv cannot be held responsible
in the event of damage or injury resulted from (incorrect) use of this device.
For more info concerning this product, please visit our website
www.velleman.eu
.
The information in this manual is subject to change without prior notice.
