Velleman LEDS09RGB User Manual
Page 2
LEDS09RGB
V. 01 – 26/07/2013
2
©Velleman nv
A
B
1
2
3
power input
to LED strip
IR LED
voedingsingang
naar ledstrip
infraroodled
entrée d’alimentation
vers ruban LED
LED infrarouge
entrada de alimentación hacia la cinta con LEDs LED infrarrojo
Netzeingang
zu LED-Leiste
IR-LED
entrada da alimentação para faixa LED
LED IR
C
D
