LX104/LX105
V. 02 – 18/03/2013 6 ©Velleman nv
menu function description
DMX
address set DMX address ( ~ )
channel mode
select 5-channel DMX mode (+ address)
select 12-channel DMX mode (+ address)
7.2 Stand-Alone Mode
Auto Mode
1. Press until
is displayed.
2. Use or to select the desired program ~ ( = loop of
~ ).
3. Press until is displayed.
4. Use or to select the desired running speed ~ ( = slow,
= fast).
Sound-Active Mode
This mode allows a single unit to run to the beat of the music.
1. Press until
is displayed.
2. Use the audio sensitivity knob on the back of the fixture [5] to make the fixture more or less
sensitive.
7.3 Slave Mode
This mode allows a unit to follow the output of a master unit which has been set to Auto or Sound-Active
mode.
1. Set the master unit to auto or sound-activated mode.
2. On each slave unit, press until
is displayed.
7.4 DMX Mode
This mode allows you to control the fixture by any universal DMX controller.
 All DMX-controlled devices need a digital start address so that the correct device responds to the
signals. This digital start address is the channel number from which the device starts to “listen” to
the DMX controller. The same starting address can be used for a whole group of devices or an
individual address can be set for every device.
 When all devices have the same address, all the units will “listen” to the control signal on one
particular channel. In other words: changing the settings of one channel will affect all devices
simultaneously. If you set individual addresses, each device will “listen” to a separate channel
number. Changing the settings of one channel will only affect the device in question.
Example:
o In case of the 5-channel LX104/LX105, you will have to set the start address of the first unit
to 1 (CH1~5), the second unit to 6 (1 + 5) (CH6~10), the third to 11 (6 + 5) (CH11~15), and
so on.
o In case of the 12-channel LX104/LX105, you will have to set the start address of the first unit
to 1 (CH1~12), the second unit to 13 (1 + 12) (CH13~24), the third to 25 (13 + 12)
(CH25~36), and so on.
1. Press until the DMX channel mode ( or ) is displayed.
2. Use or to select the desired DMX mode ( or mode)
3. Press until the DMX address ( ) is shown.
4. Use or to set the desired starting address ( ~ ).
DMX Channel Values
5-Channel Mode
channel from to description
1 000 255 dimmer 0 ~ 100%
2
000 009 no function
010 255 strobe: slow ~ fast (max. 20Hz)
