MON9TA2
V. 01 – 06/06/2013 4 ©Velleman nv
 automatic trigger function for reverse camera
 comes with: remote control, cables and table stand
 OSD (on-screen display)
 operation mode: touch buttons
5. Overview
Refer to the illustrations on page 2 of this manual.
Image A - Panel
1
input switch (AV1 – AV2 – HDMI) 4 decrease button
2 TFT menu 5 increase button
3 ON/OFF button
Image B - Remote
6
input switch (AV1 – AV2 – HDMI -
VGA) 9 menu button
7 decrease button 10 increase button
8 aspect ratio (16:9 – 4:3) 11 ON/OFF button
Image C - Batteries
12
back of remote controller 14 battery
13 battery slot 15 lock
Image D - DVD connection
16
video input 1 (yellow) 20 + 12 VDC (red)
17 video input 2 (yellow) 21 gnd (black)
18 right audio input (red) 22 cable for reverse camera (blue)
19 left audio input (white) 23 monitor jack
Image E – Back of the monitor
24
RCA port 27 power in
25 HDMI port 28 dvd connector
26 VGA port 29 speakers
6. Connecting the monitor
The numbers between brackets refer to the illustrations on page 2.
1. Choose a mounting location, depending on the purpose of the monitor.
2. Mount the mounting bracket and attach the monitor to the bracket with the screw.
3. Connect the monitor jack [23] to the monitor [28].
4. Connect a camera/video/DVD… (not incl.) to a video input [16] or [17].
5. Connect the sound output of that device to the audio inputs [18] or [19].
6. Connect the power supply to the power in [27].
7. Using the monitor
1. Press button on the monitor or remote control to switch on the monitor.
2. Press the Mode button on the monitor (remote control: Video Select) to select the input channel.
3. Press the Mode select button on the remote control to set the aspect ratio (16:9 or 4:3).
4. Press the Menu button on the monitor or remote control to enter monitor setup.
o Use the Mode button to navigate through the settings.
o Use the up () or down () buttons to change the settings
On the remote control, use the  and  buttons.
Menu options
The menu options are:
