• The display will show the temperature.
Note: without the thermocouple in place, the display will show the ambient
temperature.
Measuring frequencies
Do not perform frequency measurements in circuits with voltages
> 250V.
Always be careful when working with voltages above 60Vdc or 30Vac rms.
Keep your fingers behind the probe barriers at all times during
measurement.
• Connect the black test lead to the "COM" jack and the red test lead to the
"VΩHz" jack.
• Select the "20KHz" range with the FUNCTION switch.
• Connect the test leads to the circuit under test.
• Read the measured value from the display.
Notes:
• Use a shielded cable for measuring small signals in a noisy environment (min.
visible amplitude: 0.7Vpp).
10. Specifications
This device is not calibrated when purchased!
Regulations concerning environment of use:
• Use this meter only for measurements in CAT I and CAT II environments (see
§4)
• Use this meter only in a pollution degree 2 environment (see §5)
Ideal temperature
23°C
Ideal relative humidity
75%
Max. altitude
2000m
Overvoltage/installation category
600V CAT. II
Pollution degree
Pollution degree 2
Max. voltage between terminal and
earth
600VDC or 600Vrms AC (sine wave)
Display
3 ½ digit LCD, 2 to 3 readings/sec.
Fuse protection
200mA-range: F 0.2A/250V resettable
10A-range: ceramic F10A/250V
Power supply
9V-battery 6LF22 (only use non-
rechargeable batteries)
Ranging method
manual
Polarity indication
" - " is displayed
Overrange indication
" 1. " is displayed automatically
Battery-low indication
"
" is displayed
Operating temperature
0°C to 40°C
Storage temperature
-10°C to 50°C
Dimensions
88 x 170 x 38mm
Weight 340g
(incl.
battery)
