Velleman VDPLOP1209RGB User Manual
Page 7
VDPLOP1209RGB
V. 04 – 08/01/2013
7
©Velleman nv
•
In case of the 4-channel mode, you will have to set the start address of the first unit to 1 (CH1~4), the
second to 5 (1 + 4) (CH5~8), the third to 9 (5 + 4) (CH9~12), and so on. The highest start address is 509.
•
In case of the 5-channel mode, you will have to set the start address of the first unit to 1 (CH1~5), the
second to 6 (1 + 5) (CH6~10), the third to 11 (6 + 5) (CH11~15), and so on. The highest start address
is 508.
•
In case of the 9-channel mode, you will have to set the start address of the first unit to 1 (CH1~9), the
second to 10 (1 + 9) (CH10~18), the third to 19 (10 + 9) (CH19~27), and so on. The highest start address
is 504.
To set the device to work with a DMX controller:
1.
Press
