VDPL302FD

V. 02 – 12/07/2013

7

©Velleman nv

First unit

Second unit

Third unit

1

Start address

1

2

3

512

Channel

1

2

3

2

Start address

1

3 (1 + 2)

5 (3 + 2)

511

Channel

1~2

3~4

5~6

3

Start address

1

4 (1 + 3)

7 (4 + 3)

510

Channel

1~3

4~6

7~9

4

Start address

1

5 (1 + 4)

9 (5 + 4)

509

Channel

1~4

5~8

9~12

5

Start address

1

6 (1 + 5)

11 (6 + 5)

508

Channel

1~5

6~10

11~15

6

Start address

1

7 (1 + 6)

13 (7 + 6)

507

Channel

1~6

7~12

13~18


To set the device to work with a DMX controller:
1. Press

until 512 shows on the display.
2. Press .
3. Use or to select the starting address.
4. Press .

DMX adressing

Ch. Function

From-To

Description

Side lenses

1

Colours

000-004

No function

005-028

Red

029-056

Green

057-084

Blue

085-112

Cyan

113-140

Purple

141-168

Yellow

169-197

White

198-224

3-Colour switching

255-255

7-Colour switching

2

Strobe

000-004

No function

005-255

speed slow~fast

3

Motor Rotation

000-127

Rotation with indexing

128-255

Back and forth with increasing distance
