VDPL501MHS10
V. 01 – 30/01/2012 7 ©Velleman nv
function display description
play auto program
sound controlled mode
DMX controlled mode
slave mode
manual
control Select the setting for each channel.
display normal display
180° rotated display
colour change colour change in steps
colour change gradual
pan range 540 maximum pan range 540°
450 maximum pan range 450°
reset Press for 5 seconds to reset all settings except the
DMX starting address.
Press for 5 seconds to reset all settings including the
DMX starting address.
c. DMX Mode
This mode allows you to control the fixture by any universal DMX controller.
•
All DMX-controlled devices need a digital start address so that the correct device responds to the signals.
This digital start address is the channel number from which the device starts to “listen” to the DMX
controller. The same starting address can be used for a whole group of devices or an individual address can
be set for every device.
• When all devices have the same address, all the units will “listen” to the control signal on one particular
channel. In other words: changing the settings of one channel will affect all devices simultaneously. If you
set individual addresses, each device will “listen” to a separate channel number. Changing the settings of
one channel will only affect the device in question.
• In case of the 12-channel VDPL501MHS10, you will have to set the start address of the first unit to 1
(CH1~12), the second unit to 13 (1 + 12) (CH13~24), the third to 25 (13 + 12) (CH25~36), and so on.
• Press until is displayed.
• Use or to set the DMX starting address (A001~A512). Press to confirm.
d. DMX Channel Values
channel function from to description
1 pan 0 255 rotate head horizontally (127 = neutral)
2 tilt 0 255 move head vertically (127 = neutral)
3 pan fine 0 255 rotate head horizontally – small increments
4 tilt fine 0 255 move head vertically – small increments
5 focus 0 255 focus
6 shutter/strobe 0 0 shutter open
1 239 strobe slow -> fast
240 246 shutter closed, device resets after 5 seconds
247 247 shutter open, device resets after 5 seconds
248 255 shutter open
7 dimmer 0 255 master dimmer, 0-100%
8 colour fixed colour
1 17 white
18 35 rose
36 53 blue
54 71 yellow
72 89 green
