Synchronized Mode
1 Master Choose mode (manual, auto, sound-control)
2 Slave
6. DMX Control
Enter the DMX address with or . Confirm with ENTER.
Mode 1 – 3-channel mode
Channel Function From To Description
1 Red 0 255 From 0 ~ 100%
2 Green 0 255 From 0 ~ 100%
3 Blue 0 255 From 0 ~ 100%
Mode 2 – 4-channel mode
Channel Function From To Description
1 Master Dimmer 0 255 From 0 ~ 100%
2 Red 0 255 From 0 ~ 100%
3 Green 0 255 From 0 ~ 100%
4 Blue 0 255 From 0 ~ 100%
Mode 3 – 6-channel mode
Channel Function From To Description
1 Master Dimmer 0 255 From 0 ~ 100%
2 Red 0 255 From 0 ~ 100%
3 Green 0 255 From 0 ~ 100%
4 Blue 0 255 From 0 ~ 100%
5 Shutter
0 9 No function
10 57 Strobe from slow to fast
58 59 No function
60 108 Pulse closed from slow to fast
109 110 No function
111 159 Pulse fast closed
160 161 No function
162 255 Random strobe
6 Macros
0 9 No macro
10 50 Colour fade 1
51 91 Colour fade RGB
92 132 Colour fade 2
133 173 Colour fade 3
174 214 Colour pulse
215 255 Random all macros
DMX512 Connection
Connect an XLR cable to the female 3-pin XLR output of your controller and the other side to the
male 3-pin XLR input of the VDPLW1036. Multiple VDPLW1036s can be linked through serial
linking. The linking cable should be a two-core screened cable with XLR input and output connectors.
