VDPL300CB
V. 01 – 05/07/2012 6 ©Velleman nv
From To Description
A61 A69 Fade in and out, motor rotates from fast to slow
A71 A79 Strobe mode, motor rotates from fast to slow
So1 So1 Sound control, coloured lights and rotation
So2 So2 Sound control, white light and rotation
7.3 Master/slave mode
The master/slave mode allows for connecting several devices to a single master device. All slave devices
then work synchronously with the master device.
You need to set one device to master mode and all other devices to slave mode.
1. Connect all devices in series with DMX cables.
2. The first unit in the chain functions as the master fixture. Set up the unit as described in Stand-
alone mode.
3. On each of the connected slave units, set the DMX starting address to as follows: press
and press .
4. Repeat for each slave unit.
7.4 DMX mode
This mode allows you to control the fixture by any universal DMX controller.
• All DMX-controlled devices need a digital start address so that the correct device responds to the
signals. This digital start address is the channel number from which the device starts to “listen” to
the DMX controller. The same starting address can be used for a whole group of devices or an
individual address can be set for every device.
• When all devices have the same address, all the units will “listen” to the control signal on one
particular channel. In other words: changing the settings of one channel will affect all devices
simultaneously. If you set individual addresses, each device will “listen” to a separate channel
number. Changing the settings of one channel will only affect the device in question.
• In case of the 6-channel VDPL300CB, you will have to set the start address of the first unit to 1
(CH1~6), the second to 7 (1 + 6) (CH7~12), the third to 13 (7 + 6) (CH13~18), and so on.
To set the device to work with a DMX controller:
1. Press
DMX channel values
Channel From To Description
1
0 5 Switch
6 255 Strobe from fast to slow
2
0 0 Red off
1 255 Gradual change from dark to light
3
0 0 Green off
1 255 Gradual change from dark to light
4
0 0 Blue off
1 255 Gradual change from dark to light
5
0 5 Motor stop
5 127 Motor is turning
128 255 Motor reverse
6
0 5 Start up CH1-CH5
6 250 Built-in program, CH1-CH5 off
251 255 Sound control
