6. Use
a. DIP Switch Setting
• DMX Mode: put DIP switch 10 always to ON. For the desired address see table below:
SW10 SW9 SW8 SW7 SW6 SW5 SW4 SW3 SW2 SW1 Address
1 0 0 0 0 0 0 0 0 1
1
1 0 0 0 0 0 0 0 1 0
2
1 0 0 0 0 0 0 1 0 0
4
1 0 0 0 0 0 1 0 0 0
8
1 0 0 0 0 1 0 0 0 0 16
1 0 0 0 1 0 0 0 0 0 32
1 0 0 1 0 0 0 0 0 0 64
1 0 1 0 0 0 0 0 0 0 128
1 1 0 0 0 0 0 0 0 0 256
• Master / Slave Mode: when using the unit as master DIP switches 1 and 10 must be ON; all other DIP switches
must be OFF. For all units in slave mode, DIP switch 2 must be ON; all other DIP switches must be OFF. All units
will work synchronously according to the master.
• Sound-Activated Mode: when there is no DMX signal and DIP switch 10 is ON, the unit will go in sound-activation
mode. Control the sensitivity of the sound input using the sensitivity knob on the backside of the unit.
• Automatic Mode: when there is no DMX signal and DIP switch 1 is ON, the unit will work in automatic mode.
b. Detailed DMX Values per Channel
Channel From To Function
1
0 63
sound-activation
mode
64 127
automatic
mode
128 191 manual & sound-activation mode
192 255 DMX
mode
2
0 63
green
64
127 green – red
128 191 green
192 255 green – red
3 0
255
pattern
selection
4
0
255 pattern moving speed
5
0 63
static
pattern
64
255 flat pattern effect
6
0 63
static
gobo
64
127 fast pulse rate
128 191 middle pulse rate
192 255 slow pulse rate
7
0 63
static
gobo
64
255 up & down effect
8
0
255 effect projection speed
9 0
255
zoom
10
0
255 drawing speed from slow to fast
