VDPL3603MHW11
V. 01 – 31/01/2012
7
©Velleman nv
function display
description
play
auto program 1-2
sound controlled mode 1-2
DMX controlled mode
slave mode
manual
control
Select the setting for each channel.
display
normal
display
180°
rotated
display
reset
Press
DMX starting address.
Press
DMX starting address.
c. DMX Mode
This mode allows you to control the fixture by any universal DMX controller.
•
All DMX-controlled devices need a digital start address so that the correct device responds to the signals.
This digital start address is the channel number from which the device starts to “listen” to the DMX
controller. The same starting address can be used for a whole group of devices or an individual address can
be set for every device.
•
When all devices have the same address, all the units will “listen” to the control signal on one particular
channel. In other words: changing the settings of one channel will affect all devices simultaneously. If you
set individual addresses, each device will “listen” to a separate channel number. Changing the settings of
one channel will only affect the device in question.
•
In case of the 12-channel VDPL3603MHW11, you will have to set the start address of the first unit to 1
(CH1~12), the second unit to 13 (1 + 12) (CH13~24), the third to 25 (13 + 12) (CH25~36), and so on.
•
Press
•
Use
d. DMX Channel Values
channel function
from to
description
1 shutter/strobe
0 6 shutter
closed
7
255
strobe slow -> fast
2
dimmer
0
255
master dimmer, 0-100%
3 colour
0 4 white
5 9 red
10 14 orange
15 19 yellow
20 24 green
25 29 light
blue
30 34 blue
35 39 magenta
40 49 rose
50
150
colour change function 1
151 200 rose
201
255
colour change function 2
4
colour change speed
0
255
slow -> fast
5
pan
0
255
rotate head horizontally (127 = neutral)
6
tilt
0
255
move head vertically (127 = neutral)
7
pan fine
0
255
rotate head horizontally – small increments
8
tilt fine
0
255
move head vertically – small increments
