5. Other Functions
5.1. Setting the Auto Power-Off Timer
•
Switch on the scales.
•
Hold both and keys pressed to enter the setting mode.
•
Set the timer using the numeric keys (timer range from 0 ~ 30 min). The scales will not switch off automatically when the timer is set
to 0.
•
Press to confirm your choice.
Note: This function is only valid when powering the scales with a battery.
5.2. Calibration
•
Switch on the scales.
•
Hold both and keys pressed to enter the calibration mode.
•
Calibrate the zero point first. The scales display unit.0 in the PIECE WEIGHT window. Make sure there is no object on the platform.
Press .
•
The scales display unload in the PIECE WEIGHT window. Press to calibrate the zero point.
•
The scales will now display load in the PIECE WEIGHT window. Place a reference weight onto the platform. The reference weight
must be 25% ~ 100% FS. Press when the displayed value has stabilised.
•
The scales display inp.ld in the PIECE WEIGHT window. Now, enter the reference weight’s value using the numeric keys and press
to confirm.
•
Remove the reference weight from the platform and press to confirm the zero point again.
•
The scales will now automatically reset and return to the normal weighing mode. Exit the calibration mode by pressing . A
calibration error will be reported by cal.err.
6. Display Description
- - - - - -
Overload or overrange
- - - - - -
Uncertain value
- - - - - -
Weight signal is too small
0- - - - -
Zero point is too high
0- - - - -
Zero point is too low
Eep.er0
EEPROM cannot be accessed
Eep.er1
The EEPROM parameters differ from the backup data
Eep.er2
The parameter has not been set
Cal.err
Calibration error
Ad- - - -
Input signal over maximum range
Ad- - - -
Input signal under minimum range
Cap
Capacity-related data display
Uol
Voltage-related data display
Add
Totalised data
Pc.t
Piece weighing
Spl.pcs
Sample quantity
Up.pcs
Upper limit
Lo.pcs
Lower limit
Unload
Unload the weight from the platform
Inp.ld
Load the weight onto the platform
Cal.on
Calibration mode enabled
Cal.off
Calibration mode disabled
Use this device with original accessories only. Velleman nv cannot be held responsible in the event of damage or injury
resulted from (incorrect) use of this device.
For more info concerning this product, please visit our website www.velleman.eu.
The information in this manual is subject to change without prior notice.
