• Make sure the rotation of the mirror ball is never hampered and that no side forces can impact on the

installation.

• The installation has to be approved by an expert before the device is taken into service.

5. Use

Remove the cover of the battery operated mirror ball motor, insert a D-size alkaline battery and close the

cover.

Attach the ball + chain to the motor and set the power switch to ON. The mirror ball will start turning at

1.5 RPM.

After connecting the pin spot to the mains, the lamp will be on. By aiming the spot towards the mirror

ball, you will obtain a beautiful, colourful effect.

6. Maintenance

1. All screws should be tightened and free of corrosion.

2. The housing, the lenses, the mounting supports and the installation location should not be deformed,

modified or tampered with e.g. do not drill extra holes in mounting supports, do not change the

location of the connections, …

3. Mechanically moving parts must not show any signs of wear and tear.

4. The electric power supply cables must not show any damage. Have a qualified technician maintain the

device.

5. Disconnect the device from the mains prior to maintenance activities.

6. Wipe the device regularly with a moist, lint-free cloth. Do not use alcohol or solvents.

7. There are no user-serviceable parts, apart from the lamp (see “4. Installation”).

8. Contact your dealer for spare parts if necessary.

9. Check regularly if the key ring or chain shackles have been deformed. If so, demount the mirror ball

immediately.

7. Technical Specifications

PAR-36 Pin Spot

Power Supply

230VAC/50-60Hz

Power Consumption

max. 30W

Dimensions

∅ 120 x 160mm

Weight 1,1kg

Lamp

PAR-36 lamp [order code LAMP36, LAMP36GE (General

Electric)]

Max. Ambient Temperature

45°C

Max. Housing Temperature

100°C

Mirror Ball

Diameter

20 cm (8")

Total Weight

0,9kg

Mirror Ball Motor

Power Supply

battery, D-type, 1.5V

Rotation Speed

1.5 RPM

Maximum diameter of mirror ball

20cm (8")

Use this device with original accessories only. Velleman nv cannot be held responsible in the

event of damage or injury resulted from (incorrect) use of this device. For more info

concerning this product and the latest version of this manual, please visit our website

www.hqpower.eu. The information in this manual is subject to change without prior notice.

The copyright to this manual is owned by Velleman nv. All worldwide rights reserved.

No part of this manual or may be copied, reproduced, translated or reduced to any electronic medium or
otherwise without the prior written consent of the copyright holder.
