VDPL1803MHRGB
V. 01 – 26/10/2012
10
©Velleman nv
Channel From
To Description
70
84
Strobe 2: opening pulse (fast to slow)
85 89
Shutter
open
90
104
Strobe 3: closing pulse (fast to slow)
105 109
Shutter
open
110
124
Strobe 4: random strobe (fast to slow)
125 129
Shutter
open
130
144
Strobe 5: random opening pulse (fast to slow)
145 149
Shutter
open
150
164
Strobe 6: random closing pulse (fast to slow)
165 169
Shutter
open
170
184
Strobe 7: burst pulse (fast to slow)
185 189
Shutter
open
190
204
Strobe 8: random burst pulse (fast to slow)
205 209
Shutter
open
210
224
Strobe 9: sine wave (fast to slow)
225 229
Shutter
open
230
244
Strobe 10: burst (fast to slow)
245 255
Shutter
open
2
0
255
Master dimmer (0 ~ 100 %)
3
0
255
Pan: 0° ~ 540° / 0° ~ 630° (maximum angle is set via the menu)
4 0
255
Pan
fine
5
0
255
Tilt: 0° ~ 240°
6 0
255
Tilt
fine
7
Fixture control settings
0 9
No
function
10
14
Reset (hold for 8 seconds)
15 39
No
function
40
44
Normal motor speed
45
49
Maximum motor speed
50
54
Minimum motor speed
55 59
No
function
60
64
Maximum cooling fan speed
65 69
No
function
70
74
Cooling fan speed regulated by thermostat
75 109
No
function
110 114
Fast
dimmer
115 119
No
function
120 124
Smooth
dimmer
125 249
No
function
250 255
Illuminate
display
8
Colour wheel
0
9
Dimmer channel enabled
10 174
Various
colours
175 179
Open
Colour wheel rotation effect
180
201
Clockwise, fast to slow
202
206
Stop: stop at the colour that is active at the time
207
229
Counter-clockwise, slow to fast
230 234
Open
