VDPL1210MHRGBW
V. 02 – 26/09/2013 11 ©Velleman nv
28 channel mode
Channel From-to Function Detail
1 0-255 Pan From 0° to 540°
2 Pan fine
3 Tilt From 0 to 270°
4 Tilt fine
5 Pan/tilt speed Fast to slow
6 Pan/tilt macro 000-015: No effect
016-035: Macro 1
036-055: Macro 2
056-075: Macro 3
076-095: Macro 4
096-115: Macro 5
116-135: Macro 6
136-155: Macro 7
156-175: Macro 8
176-195: Macro 9
196-215: Macro 10
216-235: Macro 11
236-255: Macro 12
7 Pan/tilt macro speed Fast to slow, 255 = slow
8 Functions 000-069: No function
070-079: Enable blackout while pan-tilt moves
080-089: Disable blackout while pan-tilt moves
090-199: No function
200-209: Reset all
210-249: No function
250-255: Stand alone
9 Dimmer 0 to 100%, 255 = 100%
10 Strobe 000-007: Blackout
008-015: Open
016-131: Slow to fast
132-139: Open
140-181: Fast close, slow open
182-189: Open
190-231: Slow close, fast open
232-239: Open
240-247: Random
248-255: Open
11 Red 1 255 = 100%
12 Green 1 255 = 100%
13 Blue 1 255 = 100%
14 White 1 255 = 100%
15 Red 2 255 = 100%
16 Green 2 255 = 100%
17 Blue 2 255 = 100%
18 White 2 255 = 100%
19 Red 3 255 = 100%
20 Green 3 255 = 100%
21 Blue 3 255 = 100%
22 White 3 255 = 100%
23 Red 4 255 = 100%
24 Green 4 255 = 100%
25 Blue 4 255 = 100%
26 White 4 255 = 100%
