When all devices have the same address, all the units will “listen” to the control signal on one

particular channel. In other words: changing the settings of one channel will affect all devices

simultaneously. If you set different addresses, each device will “listen” to a separate channel number.

Changing the settings of one channel will only affect the device in question.

In the case of the 1-channel VDP1500SM, you will have to set the start address of the first unit to 1,

the second unit to 2 (1 + 1), the third to 3 (2 + 1), and so on.

7. Cleaning and Maintenance

1. All screws should be tightened and free of corrosion.

2. The housing, visible parts, mounting supports and the installation location (e.g. ceiling, suspension,

trussing) should not be deformed, modified or tampered with e.g. do not drill extra holes in mounting

supports, do not change the location of the connections.

3. Moving mechanic parts must not show any signs of wear and tear.

4. The electric power supply cables must not show any damage. Have a qualified technician maintain the

device.

5. Disconnect the device from the mains prior to maintenance activities.

6. Wipe the device regularly with a moist, lint-free cloth. Do not use alcohol or solvents.

7. There are no user-serviceable parts.

8. Contact your dealer for spare parts if necessary.

8. Technical Specifications

power supply

230 VAC/50 Hz

power consumption

max. 1500 W

fuse

7 A/250 V

pre-heating time

± 9 min

smoke output

± 560 m³/min

tank capacity

3 l

DMX512 connection

3-pin XLR

dimensions

471 x 267 x 200 mm

total weight

10 kg

smoke liquid

pro high-density smoke liquid (5 l) (order code VDLSLHT5, not incl.),

high-density smoke liquid (5 l) (order code VDLSLH5, not incl.) or

standard smoke liquid (5 l) (order code VDLSL5, not incl.)

cleaning liquid

smoke machine cleaning liquid (0.25 l) (order code VDLCL, not incl.)

Use this device with original accessories only. Velleman nv cannot be held responsible in the

event of damage or injury resulted from (incorrect) use of this device. For more info

concerning this product, please visit our website www.hqpower.eu. The information in this

manual is subject to change without prior notice.
