Velleman VDPL1003CW User Manual
Page 8
VDPL1003xW
25.03.2011
©Velleman nv
8
12-Channel Mode
channel LED from
to
description
1
all
000
255
dimmer 0 ~ 100%
2 all
000 009
no
function
010
255
strobe slow ~fast (max. 20Hz)
3
1
000
255
dimmer 0 ~ 100%
4
2
000
255
dimmer 0 ~ 100%
5
3
000
255
dimmer 0 ~ 100%
6
4
000
255
dimmer 0 ~ 100%
7
5
000
255
dimmer 0 ~ 100%
8
6
000
255
dimmer 0 ~ 100%
9
7
000
255
dimmer 0 ~ 100%
10
8
000
255
dimmer 0 ~ 100%
11
9
000
255
dimmer 0 ~ 100%
12
10
000
255
dimmer 0 ~ 100%
8. Cleaning and maintenance
•
All screws should be tight and free of corrosion.
•
The housing, the lenses, the mounting supports and the installation location (e.g. ceiling, suspension,
trussing) should not be deformed, modified or tampered with e.g. do not drill extra holes in mounting
supports, do not change the location of the connections …
•
The electric power supply cables must not show any damage. Have a qualified technician maintain
the device.
•
Regularly remove dust from the housing and the air vents using a slightly damp cloth.
•
There are no user-serviceable parts inside. Refer to an authorized dealer for service and/or spare
parts.
Fuse Replacement
•
Wedge the fuse holder out of its housing with a flat-head screwdriver.
•
Remove the damaged fuse from its holder and replace with exact same type of fuse.
•
Insert the fuse holder back in its place and reconnect power.
9. Technical specifications
VDPL1003CW VDPL1003WW
power supply
230VAC ~ 50Hz
power consumption
37 W
LEDs
10 x CREE® 3W cold white
10 x CREE® 3W warm white
beam angle
140°
luminous flux
1200 @ 1m
1050 @ 1m
dimensions
1060 x 58 x 148mm
weight 3.5
kg
Use this device with original accessories only. Velleman nv cannot be held responsible in the
event of damage or injury resulted from (incorrect) use of this device. The information in this
manual is subject to change without prior notice.
