User manual
1. Introduction
Thank you for choosing Velleman! Please read the manual thoroughly before bringing this device into
service. If the device was damaged in transit, do not install or use it and contact your dealer.
2. Safety Instructions
• Damage caused by disregard of certain guidelines in this manual is not covered by the warranty
and the dealer will not accept responsibility for any ensuing defects or problems.
• Damage caused by user modifications to the device is not covered by the warranty.
• Only use the device for its intended purpose. Using the device in an unauthorised way will void the
warranty.
• Check the contents prior to assembly. Use proper tools and never use defective or deformed
parts as an improper installation may cause serious injury.
• Any included hardware is for mounting on solid brick, concrete or hard wood battens.
When mounting on wood, do not use any concrete anchors. Do not use any included hardware
for mounting on steel. If uncertain about the nature of the wall or mounting techniques, please
consult an expert.
• Respect the product’s max. load specifications. Protect this device from shocks and abuse and
avoid brute force when operating. Check the installation on a bimonthly basis.
• An adequate mounting is essential and falls outside the responsibility of Velleman Components
nv. Respect all installation and operating directions of the device to be mounted/installed
(LCD/plasma display).
• Only use the device at an indoor location, protected from rain, moisture, splashing and dripping
liquids. Make sure the chosen location spot is able to support the weight of the bracket and
screen.
• Keep fingers away from articulations to avoid injury. Keep the device out of reach of children and
unauthorized users at all times.
3. General Guidelines
Refer to the Velleman® Service and Quality Warranty on the last pages of this manual.
4. Features
• for LCD TV
• easy installation
• in accordance with VESA standard 75/100mm & 100/100mm
• comes with all necessary plugs and screws for assembly and mounting
5. Installation
Refer to the illustrations on page 2 and page 3 of this manual.
1) Use the wall mounting bracket to determine and indicate the position of the mounting holes.
1a) When mounting on a brick or concrete wall, drill holes size Ø8mm, at least 50mm deep at the
indicated positions and insert anchors [H]. Fix the wall mounting bracket against the wall
using 4 screws [G]. Mount the included hook [I] as indicated in the illustration on page 2.
1b) When mounting on a wooden wall or wall support, drill holes size Ø3mm, at least 50mm deep
at the indicated positions. Make sure all the holes are blind holes. Fix the wall mounting
bracket against the wall using 4 screws [G]. Mount the include hook [I] as indicated in the
illustration on page 2.
2) Close the bottom cover and slide the cable guides top-down into the foreseen openings in the
mounting bracket.
3) Slide the bracket arm under an angle into the wall mounting bracket and push it down until a
click is heard. The bottom part must rest on the hook [I]. Close the top cover.
4) Mount the TV mounting bracket on the back of the TV, with the hook facing up (top edge of the
TV). Depending on the TV screen, use screws [C], [D], [E] or [F].
5) Hook the TV mounting bracket over the wall mounting bracket and secure it with two screws
[J] and hex wrench [A].
6) Hold the TV-screen in the desired position and secure it by tightening the 3 hex screws at the
end of the bracket arm using hex wrench [B].
