PSR-3000/1500 Data List 29
Parameters marked with a ● in the “Control” column can be controlled from an AC1 (assignable controller 1) etc. However, these only affect
insertion type effects.
Panel Effect Name Type MSB (Type LSB)
HALL1, 2, 3, 4, 5, HALLM, HALLL MSB = 01,
LSB = 0, 1, 6, 7, 16, 17, 18
ROOM1, 2, 3, 4, 5, 6, 7, ROOMS, ROOMM, ROOML MSB = 0, 2,
LSB = 0, 1, 2, 5, 6, 7, 16, 17, 18, 19
STAGE1, 2, 3, 4 MSB = 03
PLATE1, 2, 3, GM PLATE MSB = 04, LSB = 0, 7, 16, 17
(Reverb, all the DSP blocks)
LARGE HALL, MEDIUM HALL MSB = 01, LSB = 2, 3
WARM ROOM, WOODY ROOM MSB = 02, LSB = 3, 4
RICH PLATE MSB = 04, LSB = 1
(Reverb block)
DELAY LCR1, DELAY LCR2 MSB = 05
(All the DSP blocks)
DELAY LR MSB = 06
(All the DSP blocks)
ECHO MSB = 07
(All the DSP blocks)
CROSS DELAY MSB = 08
(All the DSP blocks)
No. Parameter Display Value See Table Control
1 Reverb Time 0.3 – 30.0s 0 – 69 table#4
2 Diffusion 0 – 10 0 – 10
3 Initial Delay 0.1mS – 200.0mS (*1) 0 – 127 table#5
0.1mS – 99.3mS (*2, 3) 0 – 63
4 HPF Cutoff Thru – 8.0kHz 0 – 52 table#3
5 LPF Cutoff 1.0kHz – Thru 34 – 60 table#3
6
7
8
9
10 Dry/Wet D63>W – D=W – D 1 – 127 (table#15) ●
11 Rev Delay 0.1mS – 200.0mS (*1) 0 – 127 table#5
0.1mS – 99.3mS (*2,3) 0 – 63
12 Density 0 – 4 (*1,2) 0 – 4
0 – 2 (*3) 0 – 2
13 Er/Rev Balance E63>R – E=R – E 1 – 127
14 High Damp 0.1 – 1.0 1 – 10
15 Feedback Level -63 – +63 1 – 127 (table#16)
16
No. Parameter Display Value See Table Control
1 Reverb Time 0.3 – 30.0s 0 – 69 table#4
2 Diffusion 0 – 10 0 – 10
3 Initial Delay 0.1mS – 200.0mS 0 – 127 table#5
4 HPF Cutoff Thru – 8.0kHz 0 – 52 table#3
5 LPF Cutoff 1.0kHz – Thru 34 – 60 table#3
6
7
8
9
10 Dry/Wet D63>W – D=W – D 1 – 127 (table#15) ●
11
12
13
14 High Damp 0.1 – 1.0 1 – 10
15
16
No. Parameter Display Value See Table Control
1 Lch Delay 0.1 – 1638.3ms (*2) 1 – 16383
0.1 – 1486.0ms (*3) 1 – 14860
2 Rch Delay 0.1 – 1638.3ms (*2) 1 – 16383
0.1 – 1486.0ms (*3) 1 – 14860
3 Cch Delay 0.1 – 1638.3ms (*2) 1 – 16383
0.1 – 1486.0ms (*3) 1 – 14860
4 Feedback Delay 0.1 – 1638.3ms (*2) 1 – 16383
0.1 – 1486.0ms (*3) 1 – 14860
5 Feedback Level -63 – +63 1 – 127 (table#16)
6 Cch Level 0 – 127 0 – 127 (table#18)
7 High Damp 0.1 – 1.0 1 – 10
8
9
10 Dry/Wet D63>W – D=W – D 1 – 127 (table#15) ●
11
12
13 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
14 EQ Low Gain -12 – +12dB 52 – 76
15 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
16 EQ High Gain -12 – +12dB 52 – 76
No. Parameter Display Value See Table Control
1 Lch Delay 0.1 – 1638.3ms (*2) 1 – 16383
0.1 – 1486.0ms (*3) 1 – 14860
2 Rch Delay 0.1 – 1638.3ms (*2) 1 – 16383
0.1 – 1486.0ms (*3) 1 – 14860
3 Feedback Delay 1 0.1 – 1638.3ms (*2) 1 – 16383
0.1 – 1486.0ms (*3) 1 – 14860
4 Feedback Delay 2 0.1 – 1638.3ms (*2) 1 – 16383
0.1 – 1486.0ms (*3) 1 – 14860
5 Feedback Level -63 – +63 1 – 127 (table#16)
6 High Damp 0.1 – 1.0 1 – 10
7
8
9
10 Dry/Wet D63>W – D=W – D 1 – 127 (table#15) ●
11
12
13 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
14 EQ Low Gain -12 – +12dB 52 – 76
15 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
16 EQ High Gain -12 – +12dB 52 – 76
No. Parameter Display Value See Table Control
1 Lch Delay1 0.1 – 1486.0ms (*2) 1 – 14860
0.1 – 743.0ms (*3) 1 – 7430
2 Lch Feedback Level -63 – +63 1 – 127 (table#16)
3 Rch Delay1 0.1 – 1486.0ms (*2) 1 – 14860
0.1 – 743.0ms (*3) 1 – 7430
4 Rch Feedback Level -63 – +63 1 – 127 (table#16)
5 High Damp 0.1 – 1.0 1 – 10
6 Lch Delay2 0.1 – 1486.0ms (*2) 1 – 14860
0.1 – 743.0ms (*3) 1 – 7430
7 Rch Delay2 0.1 – 1486.0ms (*2) 1 – 14860
0.1 – 743.0ms (*3) 1 – 7430
8 Delay2 Level 0 – 127 0 – 127 (table#18)
9
10 Dry/Wet D63>W – D=W – D 1 – 127 (table#15) ●
11
12
13 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
14 EQ Low Gain -12 – +12dB 52 – 76
15 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
16 EQ High Gain -12 – +12dB 52 – 76
No. Parameter Display Value See Table Control
1 L->R Delay 0.1 – 1486.0ms (*2) 1 – 14860
0.1 – 743.0ms (*3) 1 – 7430
2 R->L Delay 0.1 – 1486.0ms (*2) 1 – 14860
0.1 – 743.0ms (*3) 1 – 7430
3 Feedback Level -63 – +63 1 – 127 (table#16)
4 Input Select L, R, L&R 0 – 2
5 High Damp 0.1 – 1.0 1 – 10
6
7
8
9
10 Dry/Wet D63>W – D=W – D 1 – 127 (table#15) ●
11
12
13 EQ Low Frequency 32Hz – 2.0kHz 4 – 40 table#3
14 EQ Low Gain -12 – +12dB 52 – 76
15 EQ High Frequency 500Hz – 16.0kHz 28 – 58 table#3
16 EQ High Gain -12 – +12dB 52 – 76
Effect Parameter List / Liste der Effektparameter /
Liste des paramètres d’effets / Lista de parámetros de efectos
