17 D8T Track-Type Tractor specifications
Rippers
Type Single-Shank, Adjustable
Parallelogram
Number of Pockets 1
Maximum Clearance Raised 636 mm 25 in
(under tip, pinned in bottom hole)
Maximum Penetration 1130 mm 44.4 in
(standard tip)
Maximum Penetration Force 127.3 kN 28,620 lb
(shank vertical)
Pry out Force 222.7 kN 50,070 lb
Weight 4085 kg 9,005 lb
(without hydraulic controls)
Total Operating Weight* 38 488 kg 84,850 lb
(with SU-Blade and Ripper)
Type Multi-Shank, Adjustable
Parallelogram
Number of Pockets 3
Overall Beam Width 2464 mm 97 in
Maximum Clearance Raised 593 mm 23.35 in
(under tip, pinned in bottom hole)
Maximum Penetration 780 mm 30.7 in
(standard tip)
Maximum Penetration Force 124.2 kN 27,920 lb
(shank vertical)
Pry out Force 227.9 kN 51,230 lb
(Multi-Shank Ripper with one tooth)
Weight (one shank, without 4877 kg 10,752 lb
hydraulic controls)
Additional Shank 332 kg 732 lb
Total Operating Weight* 39 280 kg 86,597 lb
(with SU-Blade and Ripper)
* Total Operating Weight: Includes hydraulic controls, blade
tilt cylinder, coolant, lubricants, 100% fuel, ROPS, FOPS cab,
Blade, Ripper, 560 mm (22 in) MS shoes, and operator.
Transmission
1 Forward 3.4 kph 2.1 mph
2 Forward 6.1 kph 3.8 mph
3 Forward 10.6 kph 6.6 mph
1 Reverse 4.5 kph 2.8 mph
2 Reverse 8 kph 5 mph
3 Reverse 14.2 kph 8.8 mph
1 Forward – Drawbar Pull (1000) 618.5 N 139 lbf
2 Forward – Drawbar Pull (1000) 338.2 N 76 lbf
3 Forward – Drawbar Pull (1000) 186.9 N 42 lbf
Blades
Type 8SU
Capacity (SAE J1265) 8.7 m 3 11.4 yd 3
Width (over end bits) 3940 mm 12.9 ft
Height 1690 mm 5.5 ft
Digging Depth 575 mm 22.6 in
Ground Clearance 1225 mm 48.2 in
Maximum Tilt 883 mm 34.8 in
Weight* 4789 kg 10,557 lb
(without hydraulic controls)
Total Operating Weight** 38 488 kg 84,850 lb
(with Blade and Single-Shank Ripper)
Type 8U
Capacity (SAE J1265) 11.7 m 3 15.3 yd 3
Width (over end bits) 4267 mm 14 ft
Height 1740 mm 5.71 ft
Digging Depth 575 mm 22.6 in
Ground Clearance 1225 mm 48.2 in
Maximum Tilt 954 mm 37.5 in
Weight* 5352 kg 11,800 lb
(without hydraulic controls)
Total Operating Weight** 39 051 kg 86,093 lb
(with Blade and Single-Shank Ripper)
Type 8A
Capacity (SAE J1265) 4.7 m 3 6.1 yd 3
Width (over end bits) 4990 mm 16.3 ft
Height 1174 mm 3.85 ft
Digging Depth 628 mm 24.7 in
Ground Clearance 1308 mm 51.5 in
Maximum Tilt 729 mm 28.7 in
Weight* 5459 kg 12,035 lb
(without hydraulic controls)
Total Operating Weight** 39 158 kg 86,328 lb
(with Blade and Single-Shank Ripper)
* Includes blade tilt cylinder.
**Operating Weight: Includes hydraulic controls, blade tilt
cylinder, coolant, lubricants, 100% fuel, ROPS, FOPS cab, Blade,
Single-Shank Ripper, 560 mm (22 in) MS shoes, and operator.
