Track Harvester General Specifications

Undercarriage

Track Systems

D-4 Track Size with 709 C3B Final Drives

D-5 Track Size with 709 BC Final Drives

Shoe Widths

560 mm (22 in) Single Bar Grouser pads with Mud/Snow Relief

560 mm (22 in) Double Bar Grouser pads with Mud/Snow Relief

610 mm (24 in) Single Bar Grouser pads with Mud/Snow Relief

610 mm (24 in) Double Bar Grouser pads with Mud/Snow Relief

760 mm (30 in) Double Bar Grouser pads with Mud/Snow Relief

8 Lower Rollers, 2 Upper Rollers, All interchangeable

Heavy Duty “D” Tow Rings

Relief Sprockets

2 Speed Track Motor

163 kN (36,600 lb-force) Tractive Effort

193 kN (43,400 lb-force) Tractive Effort

Upper Structure

Full Lighting Package – 10 Cab-mounted Halogen Lights

Radio Ready

Radio/CD player with XM receiver

Adjustable Shock Cushioned Seat

I-QAN® Hydraulic Control System with MDL full color graphics display screen

ROPS/FOPS/OPS CAB

Heater/Air Conditioner

Heater, Artic package-includes engine, water and hydraulic oil heater

Boom Systems

6.4 m (21 ft) Main and Stick with Tool Cylinder and Linkage (Reach To Tree)

7 m (23 ft, 3 in) XL Main and Stick with Tool Cylinder and Linkage (Reach To Tree)

8.2 m (27 ft) Telescopic V-bottom Boom Configuration (Reach To Tree)

Powertrain

117 kW (157 HP) CAT C6.6 ACERT Tier III Engine

Side by Side Water/Hydraulic/Air Cooling Package

12 Volt Electrical System with Master Disconnect, 160 Amp Alternator

378 L (100 gal) Fuel Tank

Hydraulics

345 Bar (5000 psi) Variable Displacement Load Sense Hydraulic System

307 L/min (81 gpm) Hydraulic Oil Flow

230 L (60 gal) Hydraulic Oil Reservoir

Electric Hydraulic Oil Fill Pump

Oil Cooler with Thermal Bypass

Fully Proportional Electronic Controls

Weight

Without Attachment

501

N/A

15,900 kg

(35,000 lbs)

501 HD

N/A

18,000 kg

(40,000 lbs)

S = Standard

O = Optional

N/A = Not Available

501 and 501HD Track Harvesters

specifications
