8 PS-150C specifications
Steering
Steering is hydraulic power-assist for
responsive, low-effort machine handling.
Minimum turning radius:
Inside 4648 mm (15' 3")
Outside 6453 mm (21' 2")
Steering angle (each direction) 37.5°.
Hydraulic system – one 75 mm (3")
bore, double-acting cylinder powered
by a gear pump.
Service Refill Capacities
U.S.
Liters Gallons
Fuel tank* 173 45.6
Cooling system 16.1 4.2
Engine oil (w/filter) 7.3 1.9
Brake 0.3 0.08
Axle 2.7 0.71
Hydraulic tank 54.9 14.5
Water spray tank 394 104
*Note: Actual fuel tank capacity is 162 L (42.8 gal).
Frame
Frame is fabricated from welded heavy-
gauge steel plates. Integral baffle plates
prevent water surge when water
ballasted. Ballast compartments have
cover plates.
The clean, unitized design provides a
flat deck for excellent operator
mobility. The frame is designed for
easy access to all major components.
Water System
The gravity water system is efficient
and reliable. System includes
galvanized distribution bars over the
front and rear tires and retractable
nylon tire scrapers for each tire.
A polyethylene water tank is located at
the front of the machine on the
operator’s platform. A water level
gauge is on the tank within easy sight
of the operator.
Pressurized water system is optional.
Instrumentation and
Gauges
The start switch, engine throttle switch,
alternator indicator light, coolant
temperature gauge, engine oil pressure
gauge, hydraulic oil temperature gauge
and hour meter are located on the
instrument panel in front of the
operator.
Machine instrumentation and most
controls are located at the operator’s
right on the control console. This
includes the propel lever, speed selector
switch, water system control, horn and
secondary brake switch.
Operator and Machine
Protective Equipment
The Roll Over Protective Structure
(ROPS) is a two-post structure that
bolts directly onto flanges welded to the
machine frame. The structure meets
SAE J231, SAE J1040, ISO 3449 and
ISO 3471.
Backup alarm emits a 107 dB(A) alarm
whenever the machine is in reverse.
The backup alarm is standard
equipment.
Retractable seat belt is 76 mm (3")
wide and is standard equipment.
