10 PS-150C specifications
Ballast Considerations and Ground Contact Pressures
The most common method of changing
ground contact pressure is to vary the
tire pressure. Another means to change
ground contact pressure is to alter the ballast. The PS-150C can be ballasted
with sand, water, steel or a combination
of each. These three components provide varying
weight capacities, allowing the machines
to be tailored to specific requirements.
Weights (approximate)
Operating weights include lubricants, coolant, 80 kg (175 lb) operator, full fuel tank, full hydraulic system, half-full water tank
and ROPS.
Operating Weights
Model Condition Weight of Ballast Total Weight Average Weight per Wheel
PS-150C
Standard machine empty — — 4885 kg 10,775 lb 545 kg 1,200 lb
Maximum water ballast 3825 kg 8,430 lb 8710 kg 19,205 lb 970 kg 2,145 lb
Maximum wet sand ballast 8055 kg 17,760 lb 12 940 kg 28,535 lb 1440 kg 3,180 lb
PS-150C w/11-Wheel Option
Standard machine empty — — 4955 kg 10,925 lb 450 kg 993 lb
Maximum water ballast 3825 kg 8,430 lb 8780 kg 19,355 lb 798 kg 1,760 lb
Maximum wet sand ballast 8055 kg 17,760 lb 13 010 kg 28,685 lb 1183 kg 2,608 lb
PS-150C w/Heavy Weight Option
Standard machine empty — — 4955 kg 10,925 lb 551 kg 1,214 lb
Maximum water ballast 3825 kg 8,430 lb 8780 kg 19,355 lb 970 kg 2,145 lb
Maximum wet sand ballast 8055 kg 17,760 lb 13 010 kg 28,685 lb 1440 kg 3,180 lb
With 12 307 kg (27,075 lb) 12 307 kg 27,075 lb 17 273 kg 38,000 lb 1920 kg 4,222 lb
of iron and wet sand ballast
PS-150C w/Heavy Weight Option and 11-Wheel Option
Standard machine empty — — 5025 kg 11,078 lb 457 kg 1,008 lb
Maximum water ballast 3825 kg 8,430 lb 8850 kg 19,511 lb 805 kg 1,775 lb
Maximum wet sand ballast 8055 kg 17,760 lb 13 080 kg 28,836 lb 1189 kg 2,621 lb
Ballast Compartments
Ballast compartments are positioned with
a calculated balance of wheel to weight
ratio. Internal-frame baffles help prevent
surges when water ballasted.
Sand and steel ballast can be added
through large cover plates on the
operation deck and water can be added
through a fill port.
When adding water, it is recommended
that only the primary ballast chamber be
used because it is sealed.
Sand and steel ballast can be removed
through a bolt-on side cover and water
ballast can be emptied through a drain
port.
Ballast capacities
Primary 3.9 m 3 (139 ft 3 )
Secondary 0.4 m 3 (11 ft 3 )
Total 4.3 m 3 (150 ft 3 )
Ballast materials
0.028 m 3 (1 ft 3 ) of wet sand weighs 57 kg (125
lb)
0.028 m 3 (1 ft 3 ) of water weighs 28 kg (62.4 lb)
