Tandems
Height 648 mm 25.5 in
Width 236 mm 9.3 in
Sidewall thickness – inner 22 mm 0.9 in
Sidewall thickness – outer 22 mm 0.9 in
Drive chain pitch 63.5 mm 2.5 in
Wheel axle spacing 1841 mm 72.5 in
Tandem oscillation – front up 15°
Tandem oscillation – front down 25°
Moldboard
Moldboard – width 4.877 m 16 ft
Moldboard – height 787 mm 31 in
Moldboard – thickness 25 mm 1 in
Arc radius 413 mm 16.3 in
Throat clearance 126 mm 4.9 in
Cutting edge – width 203 mm 8 in
Cutting edge – thickness 25 mm 1 in
End Bit – width 152 mm 6 in
End Bit – thickness 19 mm 0.75 in
Blade Pull – base GVW 17 068 kg 37,628 lb
Blade Pull – max GVW 22 297 kg 49,156 lb
Down Pressure – base GVW 12 702 kg 28,004 lb
Down Pressure – max GVW 19 485 kg 42,957 lb
• Blade pull calculated at 0.9 traction coefficient, which is
equal to ideal no-slip conditions, and Gross Machine Weight.
Blade Range
Circle centershift – right 597 mm 23.5 in
Circle centershift – left 647 mm 25.5 in
Moldboard sideshift – right 1094 mm 43.1 in
Moldboard sideshift – left 740 mm 25.6 in
Maximum blade position angle 65°
Blade tip range – forward 40°
Blade tip range – backward 5°
Maximum shoulder reach
outside of tires
– right 2587 mm 101.9 in
– left 2282 mm 90 in
Maximum lift above ground 395 mm 15.6 in
Maximum depth of cut 488 mm 19.2 in
Operating Specifications
Top Speed – Fwd. 53.9 km/h 33.5 mph
Top Speed – Rev. 42.6 km/h 26.5 mph
Turning radius, outside front tires 8.9 m 29 ft 3 in
Steering range – left/right 47.5°
Articulation angle – left/right 20°
Fwd. 1st 4.5 km/h 2.8 mph
Fwd. 2nd 6.3 km/h 3.9 mph
Fwd. 3rd 9 km/h 5.6 mph
Fwd. 4th 12.4 km/h 7.7 mph
Fwd. 5th 19.3 km/h 12 mph
Fwd. 6th 26.8 km/h 16.7 mph
Fwd. 7th 37 km/h 23.0 mph
Fwd. 8th 53.9 km/h 33.5 mph
Rev. 1st 3.6 km/h 2.2 mph
Fwd. 2nd 6.8 km/h 4.2 mph
Fwd. 3rd 9.8 km/h 6.1 mph
Fwd. 4th 15.2 km/h 9.5 mph
Fwd. 5th 29.3 km/h 18.2 mph
Fwd. 6th 42.6 km/h 26.5 mph
Service Refill
Fuel Capacity 511 L 135 gal
Cooling system 46.5 L 12.3 gal
Hydraulic system – total 114 L 30.1 gal
– tank 65 L 17.2 gal
Engine Oil 30 L 7.9 gal
Trans./Diff./Final Drives 114 L 30.1 gal
Tandem housing (each) 121.5 L 32.1 gal
Front wheel spindle 0.9 L 0.24 gal
bearing housing
Circle drive housing 8 L 2.1 gal
Frame
Circle – diameter 1822 mm 71.75 in
Circle – blade beam thickness 50 mm 2 in
Drawbar – height 203 mm 8 in
– width 76 mm 3 in
Front frame structure
– height 356 mm 14 in
– width 324 mm 12.8 in
– thickness 14 mm 0.06 in
Front axle – height to center 688 mm 27.1 in
– wheel lean, left/right 18.2°
– total oscillation per side 32.0°
20 16M Motor Grader specifications
