Dimensions
Alldimensionsareapproximate
1
2
7
3
8
4
5
6
STD LGP
1 TrackGauge 1981mm 78in 2286mm 90in
2 WidthofTractoroverTrunnions 2880mm 113in 3423mm 135in
WidthofTractorwithoutTrunnions(std.shoes) 2591mm 102in 3200mm 126in
3 MachineHeightfromTipofGrouser
TopofStack 3365mm 132in 3365mm 132in
TopofStandardCab 3392mm 134in 3392mm 134in
FromGroundFaceofShoe 3322mm 131in 3322mm 131in
4 LengthofTrackonGround 3016mm 119in 3450mm 136in
5 LengthofBasicTractor 4608mm 181in 4608mm 181in
Withthefollowingattachmentsaddtobasictractorlength:
Ripper(withtipatgroundline) 1391mm 55in N/A
Ripper(withtipfullyraised) 1222mm 48in N/A
Winch 1032mm 41in 1032mm 41in
Drawbar 270mm 10.6in 270mm 10.6in
SBlade 977mm 38in N/A
SUBlade 1187mm 47in N/A
UBlade 1425mm 56in N/A
ABlade 1230mm 48in 1230mm 48in
6 HeightofGrouser 70mm 2.75in 70mm 2.75in
7 GroundClearance 472mm 18.6in 472mm 18.6in
GroundContactArea(std.shoes) 3.68m 2 5,698in 2 6.31m 2 9,792in 2
NumberofShoesperSide 40 44
StandardShoeWidthandType 610mm 24in 915mm 36in
MS MS
GroundPressure 69.5kPa 10.1psi 44.3kPa 6.4psi
Pitch 215.9mm 8.5in 215.9mm 8.5in
TrackRollers/Side 7 8
NumberofCarrierRollers 2 2
8 DrawbarHeight(grousertiptocenterofclevis) 719mm 28in 719mm 28in
