517 Track Skidder
Specifications
2 March 4, 2008 3:20 PM
Engine
Net Flywheel Power 89.5 kW 120 hp
Engine Model Cat® 3304 DIT
Gross Power 101 kW 136 hp
Weights
Operating Weight 18 364 kg 40,450 lb
Operating Weight 17 343 kg 38234.72 lb
Operating Specifications
Track on Ground 2910 mm 114.57 in
Travel Speed - Fwd. 1st 3.7 km/h 2.3 mph
Travel Speed - Fwd. 2nd 6.6 km/h 4.1 mph
Travel Speed - Fwd. 3rd 11.5 km/h 7.1 mph
Travel Speed - Rev. 1st 4.6 km/h 2.8 mph
Travel Speed - Rev. 2nd 8 km/h 5 mph
Travel Speed - Rev. 3rd 14.2 km/h 8.8 mph
Steering Clutch/Brake
Transmission
Transmission 3-Speed Powershift
Fuel Tank
Fuel Capacity 260 L 69 gal
Dimension
Ground Clearance 646 mm 25.43 in
Track guage - center lines 2000 mm 78.74 in
Track guage - outside 2560 mm 100.79 in
Height - top of cab 3302 mm 130 in
Length - overall 4970 mm 195.67 in
Length - track on ground 2910 mm 114.57 in
Height - grouser 57 mm 2.24 in
Height - top of guard 987 mm 38.86 in
Height - top of drum 1557 mm 61.3 in
