CL
Wirewound Resistors,
Commercial Power, Tab Type Terminals
Vishay Dale
Document Number: 30222
For technical questions, contact: [email protected]
www.vishay.com
Revision: 31-Oct-07
65
DIMENSIONS in inches [millimeters]
MATERIAL SPECIFICATIONS
Element: Nickel-chrome alloy or copper-nickel alloy,
depending on resistance value
Core: Woven fiberglass
Terminals: Electro tin plated steel
Part Marking: Resistance is stamped on terminal in two
places, maximum of three characters
0.140
[3.56]
0.140 [3.56]
G
F
Right terminal
Left terminal
D
C
A
B
E
GLOBAL MODEL
DIMENSIONS in inches [millimeters]
A
± 0.020 [0.508]
B
typical
C
± 0.010 [0.254]
D
± 0.010 [0.254]
E
± 0.005 [0.127]
CL4095
0.95 [24.13]
0.105 [2.67]
0.344 [8.73]
0.475 [12.07]
0.015 [0.38]
CL4100
1.00 [25.40]
0.105 [2.67]
0.344 [8.73]
0.475 [12.07]
0.015 [0.38]
CL4125
1.25 [31.75]
0.105 [2.67]
0.344 [8.73]
0.475 [12.07]
0.015 [0.38]
CL4150
1.50 [38.10]
0.105 [2.67]
0.344 [8.73]
0.475 [12.07]
0.015 [0.38]
CL4200
2.00 [50.80]
0.105 [2.67]
0.344 [8.73]
0.475 [12.07]
0.015 [0.38]
CL4225
2.25 [57.15]
0.105 [2.67]
0.344 [8.73]
0.475 [12.07]
0.015 [0.38]
CL4300
3.00 [76.20]
0.105 [2.67]
0.344 [8.73]
0.475 [12.07]
0.015 [0.38]
CL6095
0.95 [24.13]
0.170 [4.32]
0.344 [8.73]
0.575 [14.61]
0.018 [0.46]
CL6100
1.00 [25.40]
0.170 [4.32]
0.344 [8.73]
0.575 [14.61]
0.018 [0.46]
CL6133
1.33 [33.78]
0.170 [4.32]
0.344 [8.73]
0.575 [14.61]
0.018 [0.46]
CL6167
1.67 [42.42]
0.170 [4.32]
0.344 [8.73]
0.575 [14.61]
0.018 [0.46]
CL6200
2.00 [50.80]
0.170 [4.32]
0.344 [8.73]
0.575 [14.61]
0.018 [0.46]
CL6233
2.33 [59.18]
0.170 [4.32]
0.344 [8.73]
0.575 [14.61]
0.018 [0.46]
CL6300
3.00 [76.20]
0.170 [4.32]
0.344 [8.73]
0.575 [14.61]
0.018 [0.46]
GLOBAL MODEL
TERMINAL HOLE OPTIONS AND DIMENSIONS in inches [millimeters]
LEFT OPTION
F
± 0.010 [0.254]
G
± 0.010 [0.254]
RIGHT
OPTION
F
± 0.010 [0.254]
G
± 0.010 [0.254]
CL4000
A
0.130 [3.30]
0.160 [4.06]
A
0.130 [3.30]
0.160 [4.06]
B
0.172 [4.37]
0.210 [5.33]
B
0.172 [4.37]
0.210 [5.33]
C
0.200 [5.08]
0.220 [5.59]
E
0.200 [5.08]
0.210 [5.33]
D
0.128 [3.25]
0.128 [3.25]
D
0.128 [3.25]
0.128 [3.25]
CL6000
A
0.130 [3.30]
0.160 [4.06]
A
0.130 [3.30]
0.160 [4.06]
B
0.172 [4.37]
0.210 [5.33]
B
0.172 [4.37]
0.210 [5.33]
C
0.200 [5.08]
0.220 [5.59]
E
0.200 [5.08]
0.220 [5.59]
F
0.180 [4.57]
0.180 [4.57]
F
0.180 [4.57]
0.180 [4.57]
120
100
80
60
40
20
0
%
N I
R
E
W
O
P
D
E
T
A
R
AMBIENT TEMPERATURE IN °C
25
- 65
0
75
150
225
300
375
- 50
Derating
PERFORMANCE
TEST
CONDITIONS OF TEST
TEST LIMITS (EIA RS-344)
Thermal Shock
- 55 °C to + 275 °C, 5 cycles, 30 min dwell time
± (5.0 % + 0.05
Ω) ΔR
Short Time Overload
5 x rated power for 5 s
± (4.0 % + 0.05
Ω) ΔR
Low Temperature Operation
- 65 °C, full rated working voltage for 45 min
± (3.0 % + 0.05
Ω) ΔR
Humidity
75 °C, 90 % - 100 % RH, 240 h
± (5.0 % + 0.05
Ω) ΔR
Load Life
1000 h at rated power, + 25 °C, 1.5 h “ON”, 0.5 h “OFF”
± (10.0 % + 0.05
Ω) ΔR
Resistance to Solder Heat
Terminal immersed 3.5 s in molten solder at 1/8" to 3/16" from body
± (4.0 % + 0.05
Ω) ΔR
